Adam Audio T7V Nearfield Monitor 2-way 7" woofer


The A Series A7V speaker represents the evolution of ADAM Audio’s best-selling, award-winning A7X. The two-way A7V combines a new 7-inch woofer built from Multi-Layer Mineral (MLM) fibres and ADAM Audio’s handmade precision X-ART tweeter to deliver a wide frequency range of 41 Hz to 42 kHz. Rotatable HPS waveguide technology and onboard DSP-based tuning options enable you to optimize the sound of the A7V for your precise room requirements and sonic preferences. For many artists, mixers, and producers, the A7V will be the sweet spot in the A Series line.

• Tweeter: Rotatable X- ART Tweeter + HPS Waveguide
• Woofer: 1x 7" MLM woofer
• Woofer Voice Coil Ø: 33 mm / 1.3”
• Frequency response @ -6dB: 41 Hz - 42 kHz
• Max. peak SPL per speaker at 1 m: 105 dB SPL
• AD convertor: 24-bit
• Internal sample rate: 96 kHz
• Amplifier power RMS: 110 W (Woofer) + 20 W (Tweeter)
• Crossover frequency: 2.8 kHz
• Power rating: 300 W max
• Analog Inputs (balanced): 1x XLR
• Analog Inputs (unbalanced): 1x RCA
• Net Weight: 8.7 kg / 19 lb 3 oz
• Gross Weight: 10.7 kg / 23 lb 9 oz
• Cabinet Height x Width x Depth: 337 mm x 200 mm x 280 mm [13 1/4" x 7 7/8" x 11"]

The T7V is a two-way studio monitor designed for vertical use in a nearfield application.

The T7V features a 7” woofer that provides bass extension down to 39 Hz, while the U-ART tweeter’s diaphragm provides pristine and extended high-frequency response up to 25 kHz – virtually unheard of in monitors in this price range.

The U-ART tweeter is fitted to a precision waveguide with the same dispersion-control attributes as the High Frequency Propagation (HPS) waveguide used in ADAM Audio’s flagship S Series studio monitors.

The waveguide’s highly uniform dispersion of high frequencies provides an incredibly wide sweet spot that frees you from being glued to a rigid mix position while working.

On the rear side of the T7V’s beveled cabinet, a rear-firing bass reflex port joins a sturdy metal backplate that’s home to the analog input connections.

The U-ART tweeter is powered by a 20 W Class-D amp, while a 50 W Class-D amp serves the woofer.

These new powerhouses yield an impressive maximum of 110dB SPL per pair.

Their wide frequency response, high dynamic range, excellent transient response, wide sweet spot and small footprints make the T7V perfectly suited for use in small control rooms for music production, video post-production and broadcast production – a great fit for the modest budgets that many facilities need to work with.

The ADAM Sub8 subwoofer is the perfect match to complement the T7V to extend the capabilities of monitoring in the bottom end
